Description
Standard Features:
• Ideal for Delivery, To-Go and Pick up orders
• Control Panel with additional dry storage areas
• including: (3) small, (1) medium, (1) large. 1
• control panel required per each bank of lockers.
• Control Panel consists of standard single-column
• configuration with 21.5” touch screen, braille
• keyboard & QR code scanner, LED light (top of
• locker), item and door detection – UL Certified.
• Annual software fee for control locker (messages
• sent and received server hosting fee)
• ETL Safety and Sanitation certified to
• NSF7 standard
• Patented Hybrid Cooling Technology and
• temperature detection
• Added counterweights are standard to
• ensure even distribution of weight
• Units can be used indoor or outdoor underneath
• a canopy.
• Freezer: (-7.6F) ~ (1.5F)
• Refrigerated/Warming/Ambient 3 – in – 1 option
• Warming modes: 122F ~ 140F
• Refrigerated mode: 33F ~ 38F
• Ambient mode: 39F ~ 60F
• Combination Units – All lockers within each
• section must remain one temperature.
• Rated operating voltage AC110V±10% 50Hz
• Ratedpower Control unit≈100W
• Electrical lock drivepower 72W duration of 0.3s
• Weight Control unit about 176Ib
• Operating temperature -10°C~50°C
• Relative humidity 10% 80%RH
Model: ARLA-2
Description: 8-Door Ambient/Refrigerated/Warming
Power (AC): 115V/60Hz
Rated Input Power (W): 630
Overall Dimensions: 43.3 x 23.5 x 85.4
Box Dimensions: 19 x 21.7 x 15.6
Product Weight: 419
Cooling Method: Forced Air Cooling, Device on Top
Refrigerant: R290
Temperature Adjustment Range: Ambient Mode 39°F-60°F Refrigerated Mode 33°F-38°F Warming Mode: 122°F - 140°F
Environment Temperature: 32°F-110°F
Temperature Adjustment Accuracy: 34°F
Box Temperature Difference: ≤37.4°F
• Ideal for Delivery, To-Go and Pick up orders
• Control Panel with additional dry storage areas
• including: (3) small, (1) medium, (1) large. 1
• control panel required per each bank of lockers.
• Control Panel consists of standard single-column
• configuration with 21.5” touch screen, braille
• keyboard & QR code scanner, LED light (top of
• locker), item and door detection – UL Certified.
• Annual software fee for control locker (messages
• sent and received server hosting fee)
• ETL Safety and Sanitation certified to
• NSF7 standard
• Patented Hybrid Cooling Technology and
• temperature detection
• Added counterweights are standard to
• ensure even distribution of weight
• Units can be used indoor or outdoor underneath
• a canopy.
• Freezer: (-7.6F) ~ (1.5F)
• Refrigerated/Warming/Ambient 3 – in – 1 option
• Warming modes: 122F ~ 140F
• Refrigerated mode: 33F ~ 38F
• Ambient mode: 39F ~ 60F
• Combination Units – All lockers within each
• section must remain one temperature.
• Rated operating voltage AC110V±10% 50Hz
• Ratedpower Control unit≈100W
• Electrical lock drivepower 72W duration of 0.3s
• Weight Control unit about 176Ib
• Operating temperature -10°C~50°C
• Relative humidity 10% 80%RH
Model: ARLA-2
Description: 8-Door Ambient/Refrigerated/Warming
Power (AC): 115V/60Hz
Rated Input Power (W): 630
Overall Dimensions: 43.3 x 23.5 x 85.4
Box Dimensions: 19 x 21.7 x 15.6
Product Weight: 419
Cooling Method: Forced Air Cooling, Device on Top
Refrigerant: R290
Temperature Adjustment Range: Ambient Mode 39°F-60°F Refrigerated Mode 33°F-38°F Warming Mode: 122°F - 140°F
Environment Temperature: 32°F-110°F
Temperature Adjustment Accuracy: 34°F
Box Temperature Difference: ≤37.4°F
