Description
Standard Features:
• Stainless steel exterior and interior
• Stainless steel grease drawer
• Heavy duty 3/4” thick polished steel griddle plate
• 30,000 BTU burners per 12” section with standby pilots
• Independent manual controls for each 12” section
• Stainless steel legs standard
• 3/4” NPT rear gas connection and regulator standard
Model: ATMG-48
Burners and Control Method: 3 Burners Independent Manual Control
Gas Type: NG LP
Intake Tube Pressure (in W.C.): 45026
Per B.T.U./h: 30,000 30,000
Total B.T.U./h: 120,000 120,000
Regulator: 4" w.c. 10" w.c.
Work Area (inch): 47 9/10 x 19 9/10
Exterior Dimensions (inch): 48 × 28 3/5 × 15 1/5
Net Weight (lbs): 294
Gross Weight (lbs): 414
:
:
• Stainless steel exterior and interior
• Stainless steel grease drawer
• Heavy duty 3/4” thick polished steel griddle plate
• 30,000 BTU burners per 12” section with standby pilots
• Independent manual controls for each 12” section
• Stainless steel legs standard
• 3/4” NPT rear gas connection and regulator standard
Model: ATMG-48
Burners and Control Method: 3 Burners Independent Manual Control
Gas Type: NG LP
Intake Tube Pressure (in W.C.): 45026
Per B.T.U./h: 30,000 30,000
Total B.T.U./h: 120,000 120,000
Regulator: 4" w.c. 10" w.c.
Work Area (inch): 47 9/10 x 19 9/10
Exterior Dimensions (inch): 48 × 28 3/5 × 15 1/5
Net Weight (lbs): 294
Gross Weight (lbs): 414
:
:
