Description
Essential features
dual pid (coffee and steam)
Allows you to electronically control coffee and steam boiler temperature.
pro touch steam wands – special order
High performing steam wands that are cool to the touch.
3-button interface
Buttons of the left group (AV) or on the electronics board (EE) can be used to program the machine.
saturated groups
Ensure unsurpassed thermal stability, shot after shot.
pro app compatible
Electronic board that allows connectivity with the La Marzocco Pro App.
water sensor
Measures the conductivity and hardness of water as it enters the machine.
Options
1, 2, 3, or 4 groups
Configurations
Available as semi-automatic (EE) or automatic (AV) operation.
technical specifications
| Specifications | 1grp | 2grp | 3grp | 4grp |
|---|---|---|---|---|
| Height (in) | 20.5 | 20.5 | 20.5 | 20.5 |
| Width (in) | 20 | 28 | 37 | 46 |
| Depth (in) | 23 | 23 | 23 | 23 |
| Weight (lbs) | 90 | 130 | 164 | 236 |
| Voltage (VAC) | – 220V Single Phase – |
200V Single Phase 220V Single / 3 Phase 380V 3 phase |
200V Single Phase 220V Single / 3 Phase 380V 3 phase |
200V Single Phase 220V Single / 3 Phase 380V 3 phase |
| Wattage (min) | 2500 | 3350 | 4930 | 6930 |
| Wattage (max) | - | 5670 | 7790 | 9470 |
| Coffee Boiler Capacity (liters) | 1,8 | 3,4 | 5 | 6,8 |
| Steam Boiler Capacity (liters) | 3,5 | 7 | 11 | 15 |
